ADAM - 5510 / TPC 4 Slot Ethernet PC Based Programmable Controller DIN Rail
| Brand Name: | Advantech |
| Model Number: | ADAM-5510/TPC |
| MOQ: | 1 piece |
| Price: | $201-197 / piece |
| Delivery Time: | 1 - 3 days |
| Payment Terms: | T/T |
This 4-slot modular programmable automation controller adopts 16-bit microprocessor and ROM-DOS operating system, equipped with 10/100M Ethernet and multi serial communication ports. It supports IEC61131-3 programming and Modbus TCP/RTU protocols, with watchdog timer and battery-backed memory, stably processing analog/digital I/O signals for factory automated production lines.
- CPU: 16-bit microprocessor
- I/O Expansion Slots: 4 slots
- Flash ROM: 1.5 MB (960 KB for user applications)
- SRAM: 640 KB (384 KB battery backup)
- Operating System: ROM-DOS compatible with MS-DOS 6.22
- Real-time Clock: Supported
- Watchdog Timer: Supported
- Ethernet: 10/100Base-T RJ45, max 100 m transmission distance
- Serial Ports ×4
- COM1: RS232
- COM2: Isolated RS485, 2500 VDC isolation
- COM3: RS232 programming port
- COM4: RS232 / RS485 selectable
- Baud Rate: 1200 bps ~ 115200 bps
- RS485 Network: Up to 256 nodes, max 1.2 km
- Protocols: Modbus TCP, Modbus RTU Master & Slave
- Extra Network Functions: Web Server, FTP Server & Client, Email Alarm
- Input Voltage: 10 ~ 30 VDC
- Power Consumption: 4 W @ 24 VDC (without I/O modules)
- COM2 Communication Isolation: 2500 VDC
- Power Isolation: 3000 VDC
- I/O Module Isolation: 3000 VDC
- Operating Temperature: -10 ℃ ~ +70 ℃
- Storage Temperature: -25 ℃ ~ +85 ℃
- Humidity: 5% ~ 95% RH non-condensing
- Dimension: 231 × 110 × 75 mm
- Mounting: DIN 35 mm rail, wall mount, stackable
- Certification: CE, FCC Class A
- Development Tool: Borland C++ 3.0 for DOS with C function library
