SIE-MENS
Created with Pixso. AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
Detail Information
Place of Origin:
Switzerland
Application:
Electrical Equipment
Condition:
100%new 100%Original
Product Name:
Soft Starter
Warranty:
12 Months
Terminal Type:
Screw Terminals
Rated Frequency (f):
50/60 Hz
Net Weight:
0.4KG
Product Main Type:
PSR3
Payment Term:
T/T
Shipping Term:
DHL FEDEX EMS UPS
Service:
One-stop Service
Product Description
Product Description
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
PSR3-600-11

The softstarter PSR3-600-11 has a rated maximum operational current of 3 A with an operating voltage span from 208...600 V AC. The rated control voltage is 24 V AC/DC. PSR features a two-phase control soft start and stop through a voltage ramp. It has built-in
bypass for easy installation and energy saving. A RUN signal is available from a relay output in NO (normally open state). The
start/stop ramp and time is easy to set by three potentiometers on the front. PSR is often used in combination with a manual motor
starter (MMS) from ABB, so mechanical connection kits are available. Another popular option is Fieldbus communication, which can
be enabled by an external adaptor and a Fieldbus plug. The PSR range is our most compact softstarters with basic functionality and values. They are suitable for small three-phase motors with nominal currents from 3...105 A and can manage up to 100 starts per
hour. Common applications are, for example, pumps, fans, compressors, and conveyors.
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
AB-B Soft Starter PSR3-600-11 - 45A - 208 ... 600 V AC
Specification
Article Number (Market Facing Number)
PSR3-600-11
Product Description
The softstarter PSR3-600-11 has a rated maximum operational current of 3 A with an operating voltage span from 208...600 V AC. The
rated control voltage is 24 V AC/DC. PSR features a two-phase control soft start and stop through a voltage ramp. It has built-in
bypass for easy installation and energy saving. A RUN signal is available from a relay output in NO (normally open state). The
start/stop ramp and time is easy to set by three potentiometers on the front. PSR is often used in combination with a manual motor
starter (MMS) from ABB, so mechanical connection kits are available. Another popular option is Fieldbus communication, which can
be enabled by an external adaptor and a Fieldbus plug. The PSR range is our most compact softstarters with basic functionality and
values. They are suitable for small three-phase motors with nominal currents from 3...105 A and can manage up to 100 starts per
hour. Common applications are, for example, pumps, fans, compressors, and conveyors.
Rated Operational Voltage:
208 ... 600 V AC
Rated Control Supply Voltage (Us):
100 ... 240 V AC
Rated Control Circuit Voltage (Uc):
24 V DC
Connecting Capacity Supply Circuit
Rigid 1/2 x 0.75 ... 2.5
Product Main Type
PSR3
Function:
Soft start with voltage ramp
Soft stop with voltage ramp
Communication:
FiledBusPlug(Optional)
Degree of Protection:
acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
Ramp Time:
0 ... 20 second [unit of time]
1 ... 10 second [unit of time]
Overload Protection:
Recommended MS116 4.00 ... 10.00
Product Net Width:
121 mm
Product Net Height:
156 mm
Product Net Depth / Length:
50 mm
Product Net Weight:
0.5kg
Packaging Quantity
1
Package size unit of measure
MM
Quantity Unit
1 Piece
