Point level detection
Liquiphant FTL31-AA4U3AAWCJ
Point level switch for liquids in compact design with stainless steel housing
products details
|
Vibronic Point Level Detection Liquiphant FTL31 FTL31-AA4U3AAWCJ
| Brand Name: | E+H |
| Model Number: | FTL31-AA4U3AAWCJ |
| MOQ: | 1 piece |
| Price: | $205-210 / piece |
Detail Information
Place of Origin:
China
Warranty:
3 Years
Product Name:
Vibronic Point Level Detection
Measuring Principle:
Vibration Liquids
Characteristic / Application:
Level Switch For Liquids And Is Used In Tanks, Vessels And Pipes.
Ambient Temperature:
-40 °C ... 70 °C (-40 °F ... 158 °F)
Process Temperature:
-40 °C ... 150 °C (-40 °F ... 302 °F)
Process Pressure/max. Overpressure Limit:
Vacuum ... 40 Bar (Vacuum ... 580 Psi)
Min. Density Of Medium:
>0,7g/cm³ (>0,5g/cm³ Optional)
Main Wetted Parts:
316L
Payment Method:
100% TT
Product Description
Product Description
Point level detection
Liquiphant FTL31-AA4U3AAWCJ
Field of application
Liquiphant FTL31 is a point level switch for liquids. The FTL31 is designed for industrial applications in all industries, mainly the machinery industry. The Liquiphant is used for overfill protection or pump dry-run protection in cleaning systems. The IO-Link capability allows easy parameter setting.
Compact:
- Smallest vibronic sensor in the market
Safe:
- Continuous self-monitoring
-Reliable switching independent of media properties
Easy:
- No calibration
- Plug & play
- IO-Link connectivity
Point level switch in compact design with stainless steel housing.
* Process connections: Threads
* Temperature: -40 to +150°C (-40 to +302°F)
* Pressure: -1 to +40bar (-14.5 to 580psi)
* Surface roughness: 3.2µm
* Overfill protection and leakage detection WHG, marine approvals, final inspection report
Compact:
- Smallest vibronic sensor in the market
Safe:
- Continuous self-monitoring
-Reliable switching independent of media properties
Easy:
- No calibration
- Plug & play
- IO-Link connectivity
Point level switch in compact design with stainless steel housing.
* Process connections: Threads
* Temperature: -40 to +150°C (-40 to +302°F)
* Pressure: -1 to +40bar (-14.5 to 580psi)
* Surface roughness: 3.2µm
* Overfill protection and leakage detection WHG, marine approvals, final inspection report
Benefits
* Independent of changing media properties an accurate switching point is offered. IO-Link reduces costs and complexity due to easy configuration of the devices via engineering tools
* A real plug & play sensor is offered without any need for adjustment even with changing media. Measurement is unaffected by conductivity, build-up, turbulence, flows or air bubbles
* No calibration is required, no specific know-how or tools (e.g. software) necessary
* Robust design made of stainless steel (316L) assures highest durability
* A modular design offers different process temperatures and the widest variety of process connections and accessories in the market to fit every application
* No mechanically moved parts, free of maintenance
* Designed according to highest requirements to quality and environmental sustainability. The self-monitoring Liquiphant offers safe switching also in case of power supply loss.
* Independent of changing media properties an accurate switching point is offered. IO-Link reduces costs and complexity due to easy configuration of the devices via engineering tools
* A real plug & play sensor is offered without any need for adjustment even with changing media. Measurement is unaffected by conductivity, build-up, turbulence, flows or air bubbles
* No calibration is required, no specific know-how or tools (e.g. software) necessary
* Robust design made of stainless steel (316L) assures highest durability
* A modular design offers different process temperatures and the widest variety of process connections and accessories in the market to fit every application
* No mechanically moved parts, free of maintenance
