Proline t-mass B 150
thermal mass flowmeter 6BABL3-AADACAASAGA1G+AK
thermal mass flowmeter 6BABL3-AADACAASAGA1G+AK
The flowmeter for cost-effective measurement and easy monitoring of utility gases
products details
|
Proline T-mass B 150 Thermal Mass Flowmeter 6BABL3-AADACAASAGA1G+AK
| Brand Name: | E+H |
| Model Number: | 6BABL3-AADACAASAGA1G+AK |
| MOQ: | 1 piece |
| Price: | $1,423-1,428 / piece |
Detail Information
Place of Origin:
Germany
Warranty:
3 Years
Product Name:
Thermal Mass Flowmeter
Measuring Principle:
Thermal
Nominal Diameter Range:
DN 80 To 1500 (3 To 60")
Measured Variables:
Mass Flow, Temperature, Corrected Volume Flow, FAD Volume Flow
Max. Measurement Error:
3 % O.r. 4 % O.r. 5 % O.f.s.
Max. Process Pressure:
20 Bar G (290 Psi G)
Medium Temperature Range:
- 40 To +100 °C (- 40 To +212 °F)
Ambient Temperature Range:
- 40 To +60 °C ( - 40 To +140 °F)
Degree Of Protection:
IP66/67, Type 4X Enclosure
Payment Method:
100% TT
Product Description
Product Description
Field of application
The t-mass B 150 insertion version is suitable for large pipelines or rectangular ventilation ducts. It is designed for the cost-effective measurement of utility gases, in particular compressed air. It is a trending device aimed at sub-metering applications. Its 4-wire technology is contained within a rugged compact aluminum housing. Customer-specific settings are saved on the display and can be transferred from one device to another by means of the display.
* Measuring principle is characterized by a high operable flow range and direct mass flow measurement
* Suitable for air, nitrogen, carbon dioxide and argon in circular piping or rectangular ducts.
Device properties
* Insertion version for nominal diameter DN 80 to 1500 (3 to 60")
* Installation and removal of sensor without process interruption
* Easy installation
* Device in compact version with DC 24 V power supply
* 4-20 mA HART, pulse/frequency/switch output
* Compact and robust transmitter
* Measuring principle is characterized by a high operable flow range and direct mass flow measurement
* Suitable for air, nitrogen, carbon dioxide and argon in circular piping or rectangular ducts.
Device properties
* Insertion version for nominal diameter DN 80 to 1500 (3 to 60")
* Installation and removal of sensor without process interruption
* Easy installation
* Device in compact version with DC 24 V power supply
* 4-20 mA HART, pulse/frequency/switch output
* Compact and robust transmitter
Benefits
* Optimal process monitoring – easy measurement even at low pressures and flow velocities
* Cost-effective measurement – easy installation, negligible pressure loss and maintenance-free
* Reliable flow trending – multivariable measurement
* Fast and efficient commissioning – guided operating menus
* High plant availability – self-diagnostics and error monitoring
* Automatic recovery of data for servicing
* Suitable for air, nitrogen, carbon dioxide and argon in circular piping or rectangular ducts
* Optimal process monitoring – easy measurement even at low pressures and flow velocities
* Cost-effective measurement – easy installation, negligible pressure loss and maintenance-free
* Reliable flow trending – multivariable measurement
* Fast and efficient commissioning – guided operating menus
* High plant availability – self-diagnostics and error monitoring
* Automatic recovery of data for servicing
Specification
